Stage Series Fog Pocket Kit for 2021 Ford Bronco (w/ Steel Bumper)

Preorder: Will ship January 28, 2022 Preorder: Will ship January 28, 2022
$120.00
-
+

NOTE: Color choice is for Fog pods only. Offroad lights will be white with either color choice.

Features

  • Bolt-on fitment for 2021+ Ford Bronco with steel bumper.
  • Adds SAE-compliant fog lights, and powerful offroad lighting.
  • Harnesses included for independent control of road-legal and offroad lighting.
  • Backlight feature provides amber accent light.
  • Highly durable powdercoated stainless steel bracket.
  • Engineered and assembled in USA.

Overview

Overview. If you are looking to add some serious functionality to your Bronco, look no further! The Stage Series Fog Pocket Kit for the 2021+ Ford Bronco from Diode Dynamics adds both road-legal fog lights and powerful offroad lighting. The CAD-designed brackets allow you to mount two SS3 LED Pods and four SSC2 LED pods in the factory bumper openings. With the included harnesses, you'll be able to switch between road-legal fog lights and offroad lights with ease using your factory aux switch bank.

Lighting for Every Situation. This kit includes two SS3 LED Pods in the SAE-compliant fog beam pattern and four SSC2 LED pods in the combo beam pattern. This combination provides ideal light output whether you are on or offroad!

SS3 SAE Fog provides an extremely wide field of view, with high-intensity output over an entire 80-degree spread. It will fully illuminate the area in front of your vehicle.

SSC2 Combo pattern combines both the Driving and Flood optics, and provides maximum visibility. It shines light downrange in a focused, rectangular 40x20 degree pattern. The combo lens features a flood optic on one side and a driving optic on the other.

When installed as a pair and aimed in accordance with your state's regulations, the Fog pattern meets SAE J583 standard as a Foglamp, for legal on-road use. Please check your local laws and regulations for aiming, installation, and applicability.

White or Yellow Fog. The SS3 fog pods included with this kit are available in both cool white and selective yellow LED pod options. The white is a 6000K color temperature, which is a true cool white output, and matches most factory LED lighting. The selective yellow is a 3000K color temperature, great for high contrast in poor weather or a distinctive look on the road. The SSC2 offroad pods in both options are 6000K cool white.

Backlight Functionality. Each pod in this kit includes a distinctive Amber backlight feature that can be controlled separately using the factory aux switches. The backlight on each pod included with the kit fully illuminates the TIR optic, providing a more unique and modern look than the small indicator LEDs found in other products.

Sport, Pro, or Max. This kit is available at three different power levels. All options use high-intensity LED emitters, and TIR optics for unmatched focus and overall output. The Sport model uses high-intensity LEDs, and is the best bang for the buck you’ll find. The Pro model steps things up in a big way, with double the total power. Finally, the Max model features our SS3 Max LED pods, which have been designed with cutting-edge automotive emitters for both high power and extreme intensity. This brand new technology comes at a cost, but if you’re looking for the absolute best in lighting performance, the SS3 Max is the answer. Click the Specifications tab to see more information or view our full specification guides here: SSC2, SS3.

Separate Switches. With the included harnesses, the two SS3 pods and four SSC2 pods on this kit can be controlled independently using the factory aux switches, allowing you to switch between road-legal fog lights and offroad lights with ease. If your Bronco doesn't have a factory aux switch bank, you can pick up an extra wiring harness to control it using a toggle switch.

Proven Reliability. Stage Series LED lighting has been extensively tested for long-term operation from -40 to 185 degrees F, along with vibration, moisture intrusion, and corrosion testing. All of these tests are completed to SAE standards, just like factory components. They've also been put to the test on-road by racers and enthusiasts alike.

Experience. After over a decade in business, Diode Dynamics is one of the most trusted names in automotive LED lighting. We directly assemble and engineer our own products in the United States, allowing for higher quality and performance, with the newest and brightest LED technology. No matter what you're driving, we pride ourselves in offering only the best possible LED solutions. Please contact us if you'd like to discuss your lighting project!

What's Included

In the Box:

Sport/Pro

  • Two (2) Ford Bronco fog pocket brackets
  • Two (2) Sport or Pro SS3 LED pods
  • Four (4) Sport or Pro SSC2 LED pods
  • One (1) dual-output fog harness
  • One (1) OEM auxiliary switch 4-pin harness
  • Two (2) 3-way backlight splitters
  • Four (4) zip ties
  • Mounting hardware and guide

Max

  • Two (2) Ford Bronco fog pocket brackets
  • Two (2) Max SS3 LED pods
  • Four (4) Pro SSC2 LED pods
  • One (1) dual-output fog harness
  • One (1) OEM auxiliary switch 4-pin harness
  • Two (2) 3-way backlight splitters
  • Four (4) zip ties
  • Mounting hardware and guide

The "Yellow" kits include two Yellow SS3 LED pods, and four White SSC2 LED pods.

Warranty: 8 year warranty
Return Policy: 30-day Return with no restocking fee
100% Satisfaction Guarantee

Fitment

Note: This kit is not compatible with models that use a plastic bumper. If your vehicle uses the plastic bumper, click here.

Application: Fog Light
Make: Ford
Model: Bronco
Years: 2021


Find an error on this page? Please let us know!

Specifications

SS3 LED Pods
Lens Color/Optics

Peak Beam Intensity
(candela)

Illuminance
(lux @ 10m)
Measured Output
(lumens)
Raw Output
(lumens)
Output Color
Fog White Sport 10,600 cd 106 lux 1,520 lm 2,262 lm 6000K White
Fog White Pro 11,900 cd 119 lux 3,000 lm 5,796 lm 6000K White
Fog White Max 18,000 cd 180 lux 3,500 lm 7,920 lm 6000K White
Fog Yellow Sport 9,050 cd 91 lux 1,300 lm 1,930 lm 3000K Yellow
Fog Yellow Pro 10,900 cd 109 lux 2,700 lm 5,220 lm 3000K Yellow
Fog Yellow Max 12,500 cd 125 lux 3,500 lm 7,920 lm 3000K Yellow

SSC2 LED Pods
Lens Color/Optics

Peak Beam Intensity
(candela)

Illuminance
(lux @ 10m)
Measured Output
(lumens)
Raw Output
(lumens)
Output Color
Combo Sport 16,000 cd 160 lux 871 lm 1,130 lm 6000K White
Combo Pro 27,000 cd 270 lux 1,988 lm 2,898 lm 6000K White

SS3 Current (amps @ 13.2V): Sport: 1.1, Pro: 2.7, Max: 3
SSC2 Current (amps @ 12.8V): Sport: 0.6, Pro: 2
Power (watts): SS3 Sport: 14.5, SS3 Pro: 36, SS3 Max: 38.5, SSC2 Sport: 7.7, SSC2 Pro: 25.6
Operating Voltage: 9-16V
Polarity: Polarity Specific
Operating Temperature: -40C to 85C (-40F to 185F)
LED Emitter: Luxeon Z ES, Cree XP-L HI, Osram Boost HX
Connector(s): Deutsch DT Input
Driver Features: Constant Current
Materials: Polycarbonate Lens, Aluminum Casting, Rubber Gasket
Cooling: Passive, Pin-Fin heatsink
Compliance Ratings: SAE J575 Durability Test
Intrusion Ratings: IP67 Weatherproof
Unit Weight (lb): 7.6
Product Weight (lb): 15.1
Shipped Weight (lb): 17

Fitment

Note: This kit is not compatible with models that use a plastic bumper. If your vehicle uses the plastic bumper, click here.

Application: Fog Light
Make: Ford
Model: Bronco
Years: 2021

What's Included

In the Box:

Sport/Pro

  • Two (2) Ford Bronco fog pocket brackets
  • Two (2) Sport or Pro SS3 LED pods
  • Four (4) Sport or Pro SSC2 LED pods
  • One (1) dual-output fog harness
  • One (1) OEM auxiliary switch 4-pin harness
  • Two (2) 3-way backlight splitters
  • Four (4) zip ties
  • Mounting hardware and guide

Max

  • Two (2) Ford Bronco fog pocket brackets
  • Two (2) Max SS3 LED pods
  • Four (4) Pro SSC2 LED pods
  • One (1) dual-output fog harness
  • One (1) OEM auxiliary switch 4-pin harness
  • Two (2) 3-way backlight splitters
  • Four (4) zip ties
  • Mounting hardware and guide

The "Yellow" kits include two Yellow SS3 LED pods, and four White SSC2 LED pods.

Warranty: 8 year warranty
Return Policy: 30-day Return with no restocking fee
100% Satisfaction Guarantee

Installation

Installation Time: 1-2 hours

Tools Needed: Basic Toolset

Modification: None

Warranty

8 Year Limited Warranty
In addition to our standard 3 Year replacement warranty, this product carries an additional 5 years of protection against manufacturing defect, for a total of 8 years of warranty coverage. Click here to learn more.

Shipping

Domestic (U.S.) Shipping

All domestic (U.S.) orders ship with your choice of UPS or USPS, and all orders placed before 12 PM CST will ship the same day, if all items are in stock. Shipping costs are calculated at checkout, based on order size. Delivery usually takes just 3-5 days.

You will receive updates from our site when your order is shipped, along with a unique shipment number to ensure that your order is correctly accounted for. This allows you to easily reply to us if you have any concerns.

Have a question about your shipment? Just like any other question you might have, simply send us an email and our trained lighting and shipping experts will reply, usually the same day. Or, give us a call during normal business hours.



International Shipping

We ship to almost everywhere in the world using USPS shipping services, along with your country's postal service. Rates are calculated at checkout to ensure fair pricing. We normally offer standard mail, Priority International, and EMS Express. Please note that the shipping time can vary widely, based on your countries mail service and border policies.

Shipments are marked with the value of your purchase price. International customers are responsible for any tariffs or customs fees that may be associated with their shipment. Please check your country's laws and regulations before your purchase.

Puerto Rico: As we use standard USPS, PR is considered a US territory for mailing purposes, and can be selected as such at checkout. Shipping will be domestic U.S. rates.

Canada: We ship to Canada every day! Most small orders will cost around $10 via standard mail. We also offer Priority and Express EMS. To see exact shipping rates, please view your options at checkout. We also offer UPS service to Canada.

Europe, Asia, and AustraliaWe ship to all other countries using standard mail. You can check the shipping cost at checkout, as it will be calculated based on your cart. We offer standard mail, Priority, and EMS Express.



Customs Fees for International Shipping

Shipments are marked with the value of your purchase price. International customers are responsible for any tariffs or customs fees that may be associated with their shipment. Please check your country's laws and regulations before your purchase.

As we use only standard mail, our customers normally do not incur any type of import fees, customs fees, or tariffs for smaller shipments. However, this cannot be guaranteed, and any fees are the responsibility of the buyer. Please contact us if you have any concerns.

The following part numbers are included with this listing:

SKU Price Name Weight Driver Components
DD7182 $1290 Stage Series Fog Pocket Kit for 2021 Ford Bronco, White Max 17 lbs DD6409P Stage Series 2in Pro White Combo Standard ABL (pair), DD7177 Fog Pocket Bracket Kit for 2021 Ford Bronco (pair)
DD7181 $1090 Stage Series Fog Pocket Kit for 2021 Ford Bronco, Yellow Pro 17 lbs DD6412P Stage Series 2in Pro Yellow Combo Standard ABL (pair), DD7177 Fog Pocket Bracket Kit for 2021 Ford Bronco (pair)
DD7179 $770 Stage Series Fog Pocket Kit for 2021 Ford Bronco, Yellow Sport 17 lbs DD6391P Stage Series 2in Sport Yellow Combo Standard ABL (pair), DD7177 Fog Pocket Bracket Kit for 2021 Ford Bronco (pair)
DD7177 $120 Fog Pocket Bracket Kit for 2021 Ford Bronco (pair) 8.5 lbs
DD7178 $770 Stage Series Fog Pocket Kit for 2021 Ford Bronco, White Sport 17 lbs DD6388P Stage Series 2in Sport White Combo Standard ABL (pair), DD7177 Fog Pocket Bracket Kit for 2021 Ford Bronco (pair)
DD7180 $1090 Stage Series Fog Pocket Kit for 2021 Ford Bronco, White Pro 17 lbs DD6409P Stage Series 2in Pro White Combo Standard ABL (pair), DD7177 Fog Pocket Bracket Kit for 2021 Ford Bronco (pair)
DD7183 $1290 Stage Series Fog Pocket Kit for 2021 Ford Bronco, Yellow Max 17 lbs DD6412P Stage Series 2in Pro Yellow Combo Standard ABL (pair), DD7177 Fog Pocket Bracket Kit for 2021 Ford Bronco (pair)
