- Direct fitment on the 2014-2019 Toyota 4Runner.
- Allows you to mount one or two 30” light bar(s) in the lower grille opening.
- CAD-designed for perfect fitment and OEM-like appearance.
- Utilizes existing mounting points for easy installation - no cutting or drilling required.
Perfect Fitment. The Stealth LED Lightbar Kit for the 2014-2019 Toyota 4Runner from Diode Dynamics allows you to mount either a single SS30 Stage Series 30" LED Light Bar or dual Stage Series 30" LED Light Bars in the lower grille opening. These application-specific brackets were CAD-designed to install using factory mounting points. No cutting or drilling required! This kit retains the factory grille for a clean, OEM-like appearance.
Choose your look. The brackets included with this kit were designed for full customization. They feature multiple mounting holes, so you can mount a single 30” light bar or dual 30” light bars behind your grille and achieve the look you're after.
Designed For Performance. Using optical simulation modeling, Diode Dynamics Stage Series LED light bars have been designed for maximum functionality, with compact size, custom-engineered TIR optics, and a useful beam pattern, all in a highly durable package. Our light bars shine light in a highly-functional and useful beam pattern, much more focused than older LEDs on the market. Click here to learn more: Total Internal Reflection (TIR) Optics | Stage Series Video.
Functional Patterns. All Stage Series beam pattern options were designed with optical simulation modeling, to shape the output in a highly-functional beam pattern. No matter what your auxiliary lighting needs are, there is a Stage Series optic for you!
The Driving pattern was designed to supplement your high beams. Rather than a simple "spot" pattern, the Stage Series Driving pattern has a rectangular 20Wx8H degree pattern that is far more useful for directing light downrange at high speeds.
The Combo pattern combines both the Driving and Flood optics. It shines light downrange in a focused, rectangular 20Wx8H degree pattern while also illuminating the area around it in a full 80Wx50H degree spread. The Stage Series 30" Combo Light Bar features three driving lenses in the middle with two flood lenses on the outer edges.
Experience. After over a decade in business, Diode Dynamics is the most trusted name in automotive LED lighting. Unlike every other LED distributor, we assemble and engineer products ourselves in the United States, for high quality and fast time-to-market of the newest and brightest LED technologies. We pride ourselves in offering only quality LED products, that will exceed your expectations. Please contact us if you'd like to discuss your lighting project!
- Two (2) application-specific SS30 brackets for installation on the 2014-2019 Toyota 4Runner
- One (1) or Two (2) SS30 Stage Series lightbar(s)
- One (1) heavy-duty dual output offroad wiring harness or One (1) heavy-duty single output 2-pin offroad wiring harness
- One (1) Aux Switch Adapter Wire
- Mounting Hardware
- Installation Guide
NOTE: This kit is not compatible with the Limited or Nightshade trim levels.
Peak Beam Intensity
(lux @ 10m)
|White Driving||275,000 cd||2,750 lux||7,000 lm||11,400 lm||6000K White|
|White Combo||217,000 cd||1,690 lux||7,000 lm||11,400 lm||6000K White|
|Amber Driving||165,000 cd||1,650 lux||4,000 lm||5,700 lm||2000K Amber|
|Amber Combo||113,800 cd||1,014 lux||4,000 lm||5,700 lm||2000K Amber|
Installation Time: 1-2 hours
Tools Needed: Basic Toolset
Installation Guide: Click to download
8 Year Limited WarrantyIn addition to our standard 3 Year replacement warranty, this product carries an additional 5 years of protection against manufacturing defect, for a total of 8 years of warranty coverage. Click here to learn more.
